Longtherm RMB-110

8016100Longtherm RMB-110-110 25b AG 2 1/2"8016200Longtherm RMB-110-120 25b AG 2 1/2" bracket8016300Longtherm RMB-110-140 25b AG 2 1/2"8016400Longtherm RMB-110-160 25b AG 2 1/2" bracket8020800Longtherm RMB-110-130 25b AG 2 1/2" bracket8020900Longtherm RMB-110-150 25b AG 2 1/2"8024800Longtherm RMB-110-40 25b AG 2 1/2" bracket8024900Longtherm RMB-110-50 25b AG 2 1/2" bracket8025000Longtherm RMB-110-60 25b AG 2 1/2" bracket8025100Longtherm RMB-110-70 25b AG 2 1/2" bracket8025200Longtherm RMB-110-80 25b AG 2 1/2"8025300Longtherm RMB-110-90 25b AG 2 1/2" bracket8025400Longtherm RMB-110-100 25b AG 2 1/2"8047300Longtherm RMB-110-2-30 25b AG 2 1/2"8047400Longtherm RMB-110-2-40 25b AG 2 1/2"8047500Longtherm RMB-110-2-50 25b AG 2 1/2"8047600Longtherm RMB-110-2-60 25b AG 2 1/2"8047700Longtherm RMB-110-2-70 25b AG 2 1/2"8047800Longtherm RMB-110-2-80 25b AG 2 1/2"8047900Longtherm RMB-110-2-90 25b AG 2 1/2"8048000Longtherm RMB-110-2-100 25b AG 2 1/2"8048100Longtherm RMB-110-2-110 25b AG 2 1/2"8048200Longtherm RMB-110-2-120 25b AG 2 1/2"8048300Longtherm RMB-110-2-130 25b AG 2 1/2"8048400Longtherm RMB-110-2-140 25b AG 2 1/2"8048500Longtherm RMB-110-2-150 25b AG 2 1/2"8048600Longtherm RMB-110-2-160 25b AG 2 1/2"8119600Longtherm RMB-110-30 25b AG 2 1/2"

Product details

Identity data
EAN code
4036705219320
Manufacturer
Reflex Winkelmann GmbH
Brand
Reflex
Model
Longtherm
Product page
www.reflex-winkelmann.com/en/products/8048500
Description
Longtherm RMB-110-2-150, brazed heat exchanger, 230 °C, 25 bar
Type
RMB-110-2-150
Data
IFCExportAs
IfcHeatExchangerType
IFCExportType
PLATE
Weight
71.20 kg
ETIMClass 9.0
EC010138
Export Type to IFC As
IfcHeatExchangerType
Number of plates
150
Plate material
AISI 316L
Plate thickness
0.30 mm
Sealing material
copper
Type IFC Predefined Type
PLATE
Volume primary side
12.00 l
Volume secondary side
12.00 l
