Longtherm R_G-19

8029000Longtherm RHG-19-40 16b DN65/PN168029100Longtherm RHG-19-50 16b DN65/PN168029200Longtherm RHG-19-60 16b DN65/PN168029300Longtherm RHG-19-150 16b DN65/PN168029400Longtherm RMG-19-40 16b DN65/PN168029500Longtherm RMG-19-50 16b DN65/PN168029600Longtherm RMG-19-60 16b DN65/PN168030000Longtherm RMG-19-150 16b DN65/PN168112800Longtherm RHG-19-70 16b DN65/PN168112900Longtherm RHG-19-80 16b DN65/PN168113000Longtherm RHG-19-90 16b DN65/PN168113100Longtherm RHG-19-100 16b DN65/PN168113200Longtherm RHG-19-110 16b DN65/PN168113300Longtherm RHG-19-120 16b DN65/PN168113400Longtherm RHG-19-130 16b DN65/PN168113500Longtherm RHG-19-140 16b DN65/PN168113600Longtherm RMG-19-70 16b DN65/PN168113700Longtherm RMG-19-80 16b DN65/PN168113800Longtherm RMG-19-90 16b DN65/PN168113900Longtherm RMG-19-100 16b DN65/PN168114000Longtherm RMG-19-110 16b DN65/PN168114100Longtherm RMG-19-120 16b DN65/PN168114200Longtherm RMG-19-130 16b DN65/PN168114300Longtherm RMG-19-140 16b DN65/PN168124800Longtherm RLG-19-40 16b DN65/PN168124900Longtherm RLG-19-50 16b DN65/PN168125000Longtherm RLG-19-60 16b DN65/PN168125100Longtherm RLG-19-70 16b DN65/PN168125200Longtherm RLG-19-80 16b DN65/PN168125300Longtherm RLG-19-90 16b DN65/PN168125400Longtherm RLG-19-100 16b DN65/PN168125500Longtherm RLG-19-110 16b DN65/PN168125600Longtherm RLG-19-120 16b DN65/PN168125700Longtherm RLG-19-130 16b DN65/PN168125800Longtherm RLG-19-140 16b DN65/PN168125900Longtherm RLG-19-150 16b DN65/PN16

Product details

Identity data
EAN code
4036705179495
Manufacturer
Reflex Winkelmann GmbH
Brand
Reflex
Model
Longtherm
Product page
www.reflex-winkelmann.com/en/products/8113700
Description
Longtherm RMG-19-80, gasketed heat exchanger, 110 °C, 16 bar
Type
RMG-19-80
Data
IFCExportAs
IfcHeatExchangerType
IFCExportType
PLATE
Weight
294.00 kg
Tender text
Longtherm Screwed plate heat exchanger with stainless steel plates.The plates with adhesive-free NBR butyl seals are attached to the upper support rod and then fixed in the carbon steel frame using the clamping screws.Approval according to Pressure Equipment Directive 2014/68/EC.
ETIMClass 9.0
EC010138
Export Type to IFC As
IfcHeatExchangerType
Number of plates
80
Plate material
AISI 316L
Plate thickness
0.50 mm
Sealing material
NBR butyl
Type IFC Predefined Type
PLATE
Volume primary side
16.75 l
Volume secondary side
16.75 l
