Longtherm RMB-110

8016100Longtherm RMB-110-110 25b AG 2 1/2"8016200Longtherm RMB-110-120 25b AG 2 1/2" bracket8016300Longtherm RMB-110-140 25b AG 2 1/2"8016400Longtherm RMB-110-160 25b AG 2 1/2" bracket8020800Longtherm RMB-110-130 25b AG 2 1/2" bracket8020900Longtherm RMB-110-150 25b AG 2 1/2" bracket8024800Longtherm RMB-110-40 25b AG 2 1/2" bracket8024900Longtherm RMB-110-50 25b AG 2 1/2" bracket8025000Longtherm RMB-110-60 25b AG 2 1/2"8025100Longtherm RMB-110-70 25b AG 2 1/2"8025200Longtherm RMB-110-80 25b AG 2 1/2" bracket8025300Longtherm RMB-110-90 25b AG 2 1/2" bracket8025400Longtherm RMB-110-100 25b AG 2 1/2"8047300Longtherm RMB-110-2-30 25b AG 2 1/2"8047400Longtherm RMB-110-2-40 25b AG 2 1/2"8047500Longtherm RMB-110-2-50 25b AG 2 1/2"8047600Longtherm RMB-110-2-60 25b AG 2 1/2"8047700Longtherm RMB-110-2-70 25b AG 2 1/2"8047800Longtherm RMB-110-2-80 25b AG 2 1/2"8047900Longtherm RMB-110-2-90 25b AG 2 1/2"8048000Longtherm RMB-110-2-100 25b AG 2 1/2"8048100Longtherm RMB-110-2-110 25b AG 2 1/2"8048200Longtherm RMB-110-2-120 25b AG 2 1/2"8048300Longtherm RMB-110-2-130 25b AG 2 1/2"8048400Longtherm RMB-110-2-140 25b AG 2 1/2"8048500Longtherm RMB-110-2-150 25b AG 2 1/2"8048600Longtherm RMB-110-2-160 25b AG 2 1/2"8119600Longtherm RMB-110-30 25b AG 2 1/2"

A termék részletei

Azonosító adatok
EAN-kód
4036705219238
Gyártó
Reflex Winkelmann GmbH
Brand
Reflex
Terméktípus
Longtherm
Termék link
www.reflex-winkelmann.com/hu/termekek/8047600
Cikk rövid szövege
Longtherm RMB-110-2-60, forrasztott hőcserélő, 230 °C, 25 bar
Típus
RMB-110-2-60
Adatok
IFCExportAs
IfcHeatExchangerType
IFCExportType
PLATE
Súly
33.19 kg
ETIMClass 9.0
EC010138
Export Type to IFC As
IfcHeatExchangerType
Lemezek száma
60
Lemezek anyaga
AISI 316L
Lemezek vastagsága
0.30 mm
Tömítőanyag
Vörösréz
Type IFC Predefined Type
PLATE
Primeroldal tartalma (k2/k3)
4.80 l
Szekunder oldal tartalma (k4/k1)
4.80 l
