Refix DT

Lo specialista dell'acqua potabile per i grandi impianti. Il vaso espansione è attraversato dal flusso per non avere mai acqua stagna nel vaso ed è quindi adatto a soddisfare gli elevati requisiti in materia di igiene secondo DIN 1988. La molteplicità di varianti di collegamento consente un'eccellente adattabilità delle prestazioni.

7309000Refix DT 60 GN 10/4b Rp 1 1/4"7309100Refix DT 80 GN 10/4b Rp 1 1/4"7309200Refix DT 100 GN 10/4b Rp 1 1/4"7309300Refix DT 200 GN 10/4b Rp 1 1/4"7309400Refix DT 300 GN 10/4b Rp 1 1/4"7309500Refix DT 500 GN 10/4b Rp 1 1/4"7310306Refix DT 80 GN 16/4b DN65/PN167310307Refix DT 80 GN 16/4b DN80/PN167314205Refix DT 300 GN 16/4b DN65/PN167314206Refix DT 300 GN 16/4b DN80/PN167316005Refix DT 80 GN 16/4b Rp 1 1/4"7319205Refix DT 300 GN 16/4b Rp 1 1/4"7319305Refix DT 400 GN 10/4b Rp 1 1/4"7320105Refix DT 1000/1000 GN 10/2b DN65/PN167320205Refix DT 1000/1000 GN 16/2b DN65/PN167320305Refix DT 1500 GN 10/2b DN65/PN167320405Refix DT 1500 GN 16/2b DN65/PN167320505Refix DT 2000 GN 10/2b DN65/PN167320605Refix DT 2000 GN 16/2b DN65/PN167320705Refix DT 3000 GN 10/2b DN65/PN167320805Refix DT 3000 GN 16/2b DN65/PN167335705Refix DT 80 GN 10/4b DN65/PN167335805Refix DT 80 GN 10/4b DN80/PN167336305Refix DT 300 GN 10/4b DN65/PN167336405Refix DT 300 GN 10/4b DN80/PN167336505Refix DT 400 GN 10/4b DN65/PN167336605Refix DT 400 GN 10/4b DN80/PN167336705Refix DT 600 GN 10/4b DN65/PN167336806Refix DT 600 GN 10/4b DN80/PN167336905Refix DT 800 GN 10/2b DN65/PN167337006Refix DT 800 GN 10/2b DN80/PN167337105Refix DT 1000/740 GN 10/2b DN65/PN167337205Refix DT 1000/740 GN 10/2b DN80/PN167337305Refix DT 1000/1000 GN 10/2b DN80/PN167337405Refix DT 1000/1000 GN 10/2b DN100/PN167337505Refix DT 1500 GN 10/2b DN80/PN167337605Refix DT 1500 GN 10/2b DN100/PN167337705Refix DT 2000 GN 10/2b DN80/PN167337805Refix DT 2000 GN 10/2b DN100/PN167337905Refix DT 3000 GN 10/2b DN80/PN167338005Refix DT 3000 GN 10/2b DN100/PN167339005Refix DT 400 GN 16/4b DN80/PN167339006Refix DT 400 GN 16/4b DN65/PN167339105Refix DT 600 GN 16/4b DN65/PN167339205Refix DT 600 GN 16/4b DN80/PN167339305Refix DT 800 GN 16/2b DN65/PN167339406Refix DT 800 GN 16/2b DN80/PN167339505Refix DT 1000/740 GN 16/2b DN65/PN167339605Refix DT 1000/740 GN 16/2b DN80/PN167339705Refix DT 1000/1000 GN 16/2b DN80/PN167339805Refix DT 1000/1000 GN 16/2b DN100/PN167339905Refix DT 1500 GN 16/2b DN80/PN167340005Refix DT 1500 GN 16/2b DN100/PN167340105Refix DT 2000 GN 16/2b DN80/PN167340205Refix DT 2000 GN 16/2b DN100/PN167340305Refix DT 3000 GN 16/2b DN80/PN167340405Refix DT 3000 GN 16/2b DN100/PN167365000Refix DT 80 GN 10/4b DN50/PN167365100Refix DT 200 GN 10/4b DN50/PN167365105Refix DT 200 GN 10/4b DN65/PN167365106Refix DT 200 GN 10/4b DN80/PN167365108Refix DT 200 GN 16/4b Rp 1 1/4"7365200Refix DT 300 GN 10/4b DN50/PN167365300Refix DT 500 GN 10/4b DN50/PN167365305Refix DT 500 GN 10/4b DN80/PN167365307Refix DT 500 GN 10/4b DN65/PN167365400Refix DT 100 GN 10/4b DN50/PN167365405Refix DT 100 GN 10/4b DN65/PN167365406Refix DT 100 GN 10/4b DN80/PN167365408Refix DT 100 GN 16/4b Rp 1 1/4"7365500Refix DT 400 GN 10/4b DN50/PN167365600Refix DT 600 GN 10/4b DN50/PN167365700Refix DT 800 GN 10/2b DN50/PN167365800Refix DT 1000/740 GN 10/2b DN50/PN167370000Refix DT 80 GN 16/4b DN50/PN167370100Refix DT 100 GN 16/4b DN50/PN167370101Refix DT 100 GN 16/4b DN65/PN167370102Refix DT 100 GN 16/4b DN80/PN167370200Refix DT 200 GN 16/4b DN50/PN167370205Refix DT 200 GN 16/4b DN65/PN167370206Refix DT 200 GN 16/4b DN80/PN167370300Refix DT 300 GN 16/4b DN50/PN167370400Refix DT 400 GN 16/4b DN50/PN167370500Refix DT 500 GN 16/4b DN50/PN167370505Refix DT 500 GN 16/4b DN80/PN167370507Refix DT 500 GN 16/4b DN65/PN167370600Refix DT 600 GN 16/4b DN50/PN167370700Refix DT 800 GN 16/2b DN50/PN167370800Refix DT 1000/740 GN 16/2b DN50/PN16

Dettagli del prodotto

Dati di identità
Codice EAN
4036705069246
Fabbricante
Reflex Winkelmann GmbH
Brand
Reflex
Tipo di prodotto
Refix
Link prodotto
www.reflex-winkelmann.com/it/prodotti/7339805
Testo articolo breve
Refix DT 1000/1000, vaso di espansione a membrana con precarica, verde, 16/2 bar
Tipo
DT 1000/1000
Dati
IFCExportAs
IfcTankType
IFCExportType
EXPANSION
Peso
488.00 kg
Colore
green
Attacco
DN100/PN16
Diametro
1000 mm
ETIMClass 9.0
EC010958
Export Type to IFC As
IfcTankType
Volume utile netto max
900 l
Type IFC Predefined Type
EXPANSION
