Longtherm RLB-110

8015100Longtherm RLB-110-50 25b AG 2 1/2" bracket8015200Longtherm RLB-110-60 25b AG 2 1/2"8015300Longtherm RLB-110-70 25b AG 2 1/2"8015400Longtherm RLB-110-80 25b AG 2 1/2" bracket8019900Longtherm RLB-110-90 25b AG 2 1/2" bracket8020000Longtherm RLB-110-100 25b AG 2 1/2" bracket8020100Longtherm RLB-110-110 25b AG 2 1/2" bracket8020200Longtherm RLB-110-120 25b AG 2 1/2" bracket8020300Longtherm RLB-110-130 25b AG 2 1/2" bracket8020400Longtherm RLB-110-140 25b AG 2 1/2" bracket8020500Longtherm RLB-110-150 25b AG 2 1/2" bracket8020600Longtherm RLB-110-160 25b AG 2 1/2"8048700Longtherm RLB-110-2-30 25b AG 2 1/2"8048800Longtherm RLB-110-2-40 25b AG 2 1/2"8048900Longtherm RLB-110-2-50 25b AG 2 1/2"8049000Longtherm RLB-110-2-60 25b AG 2 1/2"8049100Longtherm RLB-110-2-70 25b AG 2 1/2"8049200Longtherm RLB-110-2-80 25b AG 2 1/2"8049300Longtherm RLB-110-2-90 25b AG 2 1/2"8049400Longtherm RLB-110-2-100 25b AG 2 1/2"8049500Longtherm RLB-110-2-110 25b AG 2 1/2"8049600Longtherm RLB-110-2-120 25b AG 2 1/2"8049700Longtherm RLB-110-2-130 25b AG 2 1/2"8049800Longtherm RLB-110-2-140 25b AG 2 1/2"8049900Longtherm RLB-110-2-150 25b AG 2 1/2"8050000Longtherm RLB-110-2-160 25b AG 2 1/2"

Product details

Identity data
Code EAN
4036705178702
Fabricant
Reflex Winkelmann GmbH
Brand
Reflex
Type de produit
Longtherm
Lien produit
www.reflex-winkelmann.com/fr/produits/8015400
Texte court article
Longtherm RLB-110-80, échangeur de chaleur brasé, 230 °C, 25 bar
Type
RLB-110-80
Data
IFCExportAs
IfcHeatExchangerType
IFCExportType
PLATE
Poids
41.90 kg
ETIMClass 9.0
EC010138
Export Type to IFC As
IfcHeatExchangerType
Nombre de plaques
80
Matériau des plaques
AISI 316L
Épaisseur des panneaux
0.30 mm
Matériau du joint
Cuivre
Type IFC Predefined Type
PLATE
Contenance côté primaire (k2/k3)
6.40 l
Contenance côté secondaire (k4/k1)
6.40 l
